Deprag Pneumatic Shears

Item No. S20-180Y

Category: / Air Tools / Pneumatic Shears

Our metal shear - for the entire sheet-metal industry, for the processing of metals in the automotive-, container-, and shipbuilding industry, as well as in body shops. The shear can be used for either straightor curved incisions and is expecially well-suited for the cutting of metal sheets and coils.

Sheet metal tool - Metal shear - twist valve, cutting of curved surfaces is possible, perfect cutting accuracy.

Max. power output	320 W / .43 hp
Cutting speed up to	7 m/min / 22.96 ft/min
Impacts (at full load)	1800 min^-1
Max. sheet metal thickness up to 400 N/mm²	2 mm / 0.08 in
Max. sheet metal thickness up to 600 N/mm²	1,6 mm / .06 in
Max. sheet metal thickness up to 800 N/mm²	1,4 mm / .06 in
Max. aluminium thickness up to 400 N/mm²	2,5 mm / .10 in
Assortment	Additional Assortment
Air consumption (loaded)	0,4 m³/min / 14.12 cfm
I.D. of air inlet hose	6 mm / .24 in
Weight	1,9 kg / 4.19 lbs
Air connection	thread 1/4" male
Smallest cutting radius	20 mm / .79 in
Operating pressure	6,3 bar / 90 psi
